Water Electrolysis Evaluation Equipment
- Designed to evaluate the performance, efficiency, and operational stability of water electrolysis systems
- Enables accurate measurement of electrical characteristics, hydrogen production rate, and energy efficiency
- Supports long-term durability testing under controlled operating conditions
- Applicable to PEM and alkaline water electrolysis systems
- Widely used for R&D, system validation, quality assurance, and performance benchmarking
- Power Supply
| Max Power | 5KW (125V/ 40A, 40V/83A) |
| Full Scale Voltage Range | 40/60 V |
| Voltage Resolution | ±0.1 of Full Scale |
| Power Source | 380~400VAC, 50/60 Hz |
| Power Supply Option (1.7kW) | 6V/220A, 8V/200A, 12V/140A |
- Water Handling
| Material | SUS316L, PFA |
| Water Tank Volume | 5L (Water Level 3L), Auto-Water Supply |
| Circulation Pump* | 0.15~3L/min, Software Controlled |
| Operating Temperature Range | Ambient to 70°C |
| Liquid / Gas Separator | H₂ Condenser, Heat Exchanger Water trap |
| Purge Gas (N₂) | Software Controlled |
- Stack Instrumentation
| EIS | 0.1~10kHz |
| Cell Voltage Measurement | 24 cell |
| Leakage Current Measurement | 0~5A, Accuracy 3% |
| Pressure Sensor* | 0~10 bar. g |
| Temperature Sensor* | K-Type |
| Purity Sensor | O₂ In Product H₂, H₂O In Product H₂ |
| Mass Flow Meter* | 0~50L/min |
- Physical and Environment
| Operating Temperature | 5~40°C |
| Size (WDH) | 840mm1,300mm1,900mm |
| Power Source | 220~240VAC, 50/60Hz |
| Weight | 250kg |
